Set the electrical properties and trimming parameters then select the suitable point on the net where the pattern should be inserted. The selected net is highlighted and the trim net connection length window appears showing information regarding the net properties, electrical properties and trimming parameters. Select this function tool and click on the net whose length is to be trimmed. The shape of the pattern, its amplitude and step length may be set as parameters for calculation of necessary number of steps.It is possible to see how changing of length and average trace width affects net’s electrical properties (resistance, capacitance, inductance and impedance)
This feature allows trimming of net connection by inserting pattern of segments into selected trace in order to obtain specified length. Parameters may be adjusted during this time until permanent insertion is confirmed by the mouse click. The pattern (generated according to currently set parameters) is visible and follows cursor while it is moved along the trace. lines that the layout editor creates to fill a crosshatched shape. Set the trimming parameters and select the suitable point in the trace where the pattern should be inserted. PCB Editor offers users the ability to define how a Dynamic Copper Shape is displayed. The selected trace is highlighted in white and the Equalize length of two traces property window appears with the longer and shorter trace properties and trimming parameters. Select this function tool and click on the first trace for length equalizing, The selected trace is highlighted in blue and a property window with the trace property appears.Ĭlick on the second trace which is to be equalized. The shape of the pattern, its amplitude and step length may be set as parameters for calculation of necessary number of steps. This feature allows trimming of two traces to same length by inserting pattern of segments into selected trace in order to obtain specified length. Share and edit your design with clients/colleagues in real-time. View and edit swatches on 6 x 3D 360 garment shapes. The pattern which is generated according to currently set parameters is visible and follows cursor while it is moved along the trace. Edit and view colourways using RGB colour change.
